| Specifications | |
| Protocol | DVI1.0 Protocol |
| Pixel Bandwidth | 165MHz |
| Interface Bandwidth | 2.25Gbps, full digital (total 6.75Gbps, each color 2.25Gbps) |
| Gain | 0dB |
| Max. Support Resolution | HDTV : 1920x1080P@60 |
| HDPC : 1920x1200P@60 | |
| Connector | 4 3.5mm audio socket |
| 4 DVI-D female Connectors | |
| Rise Time | <0.3 Tbit (20%–80%) |
| Fall Time | <0.3 Tbit (20%–80%) |
| Clock Jitter | <0.15 Tbit |
| Max. Transmission Delay | 5nS(+/-1nS) |
| Signal Strength | T.M.D.S +/- 0.4Vpp |
| Min./Max. Level | T.M.D.S 2.9V/3.3V |
| EDID | N/A |
| Impedance | 50 Ω |
| Max. DC Offset error | 15mV |
| Recommended max. input/output distance | Output less than 7 meters (1600×1200@60). Recommended use certified DVI Special wire such as Molex TM Wire |
| Max. Power Dissipation | 15W |
| Product Weight | About 0.5kg |
